شركة كاميرات مراقبة بالاسكندرية hikvision



مواصفات كاميرات هيك فيجين

Image Sensor:1MP CMOS Image Sensor
Signal System:PAL/NTSC
Effective Pixels:1296(H)x732(V)
Min. Illumination:0.1 Lux @(F1.2,AGC ON), 0 Lux with IR
Shutter Time:1/25(1/30) s to 1/50,000 s
Lens:3.6mm (2.8mm, 6mm optional), Angle of View: 70.9°(3.6mm), 92°(2.8mm), 56.7°(6mm)
Lens Mount:M12
Adjustment Range:Pan: 0 - 360°, Tilt: 0 - 180°, Rotation: 0 - 360°
Day& Night:IR cut filter with auto switch
Video Frame Rate:720p@25fps/720p@30fps
HD Video Output:1 Analog HD output
Synchronization:Internal Synchronization
S/N Ratio:More than 62 dB
General
Operating Conditions:40 °C - 60 °C (-40 °F - 140 °F)
Humidity 90% or less (non-condensing)
Power Supply:12 VDC±15%

Power Consumption:Max. 4W
Weather Proof:IP66
IR Range:Up to 20m
Dimension:70×149.5 mm (Φ2.76"" ×5.89"")
Weight:300 g
  • • 1.0 Megapixel high-performance CMOS
    • Analog HD output, up to 720P resolution
    • True Day/Night
    • DNR, Smart IR
    • Up to 20m IR distance
    • IP66 weatherproof

Image Sensor:1MP CMOS Image Sensor
Signal System:PAL/NTSC
Effective Pixels:1296(H)x732(V)
Min. Illumination:0.1 Lux @(F1.2,AGC ON), 0 Lux with IR
Shutter Time:1/25(1/30) s to 1/50,000 s
Lens:3.6mm (2.8mm, 6mm optional), Angle of View: 70.9°(3.6mm), 92°(2.8mm), 56.7°(6mm)
Lens Mount:M12
Adjustment Range:Pan: 0 - 360°, Tilt: 0 - 180°, Rotation: 0 - 360°
Day& Night:IR cut filter with auto switch
Video Frame Rate:720p@25fps/720p@30fps
HD Video Output:1 Analog HD output
Synchronization:Internal Synchronization
S/N Ratio:More than 62 dB
General
Operating Conditions:40 °C - 60 °C (-40 °F - 140 °F)
Humidity 90% or less (non-condensing)
Power Supply:12 VDC±15%
Power Consumption:Max. 4W
Weather Proof:IP66
IR Range:Up to 20m
Dimension:70×149.5 mm (Φ2.76"" ×5.89"")
Weight:300 g
  • • 1.0 Megapixel high-performance CMOS
    • Analog HD output, up to 720P resolution
    • True Day/Night
    • DNR, Smart IR
    • Up to 20m IR distance
    • IP66 weatherproof

    تقدم شركة رايز حلول متكاملة لأنظمة كاميرات المراقبة للشركات بمختلف الانشطة التجارية.
    يمكنك طلب خدماتنا عن طريق موقعنا:
    https://www.rise.company
    أو عن طريق الاتصال بنا
    هاتف: 01000001637 "9am ~ 5pm"
